Custom GHH IP65 Led Triproof light Manufacturers, Suppliers

Model	L(mm)	W(mm)	H(mm)	LF(mm)
GH106H	650	76	76	400
GH112H	1150	76	76	700
GH115H	1450	76	76	1000

Code

Input Voltage

Line

Output power

LED

CCT

CRI

LED quantity

Luminous flux

IP Rating

Dimensions mm

GH106H

220-240V 50/60HZ

1 PCB

18W

2835

3000K-6500K

≥80

2200lm

650

400

GH112H

220-240V 50/60HZ

1 PCB

20W

2835

3000K-6500K

≥80

2400lm

1150

700

GH112H

220-240V 50/60HZ

1 PCB

38W

2835

3000K-6500K

≥80

102

4500lm

1150

700

GH115H

220-240V 50/60HZ

1 PCB

29W

2835

3000K-6500K

≥80

3500lm

1450

1000

GH115H

220-240V 50/60HZ

1 PCB

57W

2835

3000K-6500K

≥80

153

6600lm

1450

1000

Product description
Input Voltage/Frequency	AC220-240V 50/60Hz
Installation	Easy and quick to install under ceiling or on surface
Housing/Diffuser	PC material, could meet IK08 and 850℃ GWT requirement
Driver	PHILIPS CERTA/ Tridonic SNC2
LED Brand	SMD2835
CRI	>80
Light Efficiency	130lm/W for option
Power Factor	PF>0.95
Warranty	5 years
Operating Temp Range	-20℃~50℃
Certificated	ROHS/ CE/ CB/ SAA/

Options:1.Emergency kits

2.M.sersors
3.Dali

Ningbo Fenghua Lamp Co., Ltd.

In Zhangqi town , Cixi, China, bordering east and famous Beilun port, west to the world’s longest Hangzhou Bay Bridge, is connected with the sea and air transportation is convenient. Ningbo Fenghua Lamp Co.,Ltd is professional GHH IP65 Led Triproof light manufacturers and GHH IP65 Led Triproof light suppliers in China. FengHua lighting have owned R&D team, complete production line and strict quality control system and sales team. For customer’s requirements, company is certificated by ISO9001 and ISO14001. All of our products have been approved by CE, CB ,SAA, etc. Company adhering to the“dedicated, win-win beyond” as operation policy, hope to go green and environmental lighting in future is our goals, Fenghua, Light your life.
